30 Amp AC/DC Toggle Double Pole Magnetic Circuit Breaker |UL Certified
Product details
| Management number | 231927363 | Release Date | 2026/06/18 | List Price | US$9.20 | Model Number | 231927363 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Family:Hydraulic Magnetic Circuit Breaker Voltage:125/250/277/415; 65/80 Vdc Rated Current: 30A Mounting:Rear Mounted, Operating Temperature:-40oC (-40oF) to 85oC (185oF) Interrupt Capacity: 5,000A (PC1) 3,000A @ 250 Vac (SC) 1,000A @ 415 Vac (SC) 2,000A @ 80 Vdc (SC) RoHS:Y Regulatory Sepcification:cUL1077; EN60934; EN60947; DIN; CE Technical Specification Temperature : -40 C to +85 C Shock : 50G, 11ms or 100G, 6ms Vibration : 10 to 500 Hz. 10G(1.6 mm to 50 Hz) Life : 10,000 Switching opearation with 6,000 at rate current Approximate weight: 1P-85g Dielectric Streight: 2,500 Vac 50 / 60 Hz Rated Current: 1-100A according requirement Torgue Allowed for inserts screw : M3 / 6-32 (0.6'0.8 Nm) Package: 1pcs Double Pole Hydraulic Magnetic Circuit Breakers
- High-Capacity Circuit Protection: 30 Amp, Double pole, toggle switch, panel mount, Magnetic Hydraulic 30A Circuit Breaker designed for reliable electrical protection
- Dual Functionality Design: Combines switching and circuit protection into a single device for convenient operation and space efficiency
- Extended Operational Life: 10,000 Switching operations with 6,000 cycles at rated current for long-lasting performance
- Wide Voltage and Temperature Range: Voltage ratings of 125/250/277/415Vac and 65/80 Vdc, operating temperature range from -40C to +85C
- Certified Safety Standards: Regulatory specifications include cUL1077, EN60934, EN60947, DIN, and CE certifications for quality assurance
- Versatile Marine and Automotive Applications: Suitable for use in yachts, campers, RVs, automotive vehicles, and caravans
- Manual Reset Functionality: Features a manual reset switch for easy control and safety management after circuit interruption
| ASIN | B0BX267DYV |
|---|---|
| Model | 30A Double Pole |
| Voltage | 415 Volts |
| Brand Name | T Tocas |
| Unit Count | 1.0 Count |
| Part Number | F3880-2P-30A |
| Manufacturer | Gloso |
| Mounting Type | Panel Mount |
| Current Rating | 30 Amps |
| Number of Poles | 2 |
| Included Components | Magnetic Circuit Breaker |
| Circuit Breaker Type | Standard |
| Warranty Description | 6 Month Warranty Against Manufacturer Defects |
| Smart Home Compatibility | Not Smart Home Compatible |
